轴承型号

基本尺寸(mm)

螺纹

重量(g)

Bearing No.

Principal dimensions

Thread

Weight

B(H7)

W(-0.1)

O

H(-0.1)

D

F

A(+2)

J

K

L

A/F(-0.3)

S

PHS 5 R/L

5

8

7.7

6

17

27

12

9

11

4

9

5x0.8

18

PHS 6 R/L

6

9

8.9

6.7

19

30

14

10

13

5

11

6x1.0

27

PHS 8 RF/LF

8

12

10.4

9

24

36

17

13

16

5

14

8x1.0

48

PHS 8 R/L

8x1.25

PHS 10 RF/LF

10

14

12.9

10.5

27

45

21

15

19

7

17

10x1.25

82

PHS 10 R/L

10x1.5

PHS 12 RF/LF

12

16

15.4

12

32

50

24

18

22

7

19

12x1.25

123

PHS 12 R/L

12x1.75

PHS 14 RF/LF

14

19

16.8

14

36

57

27

20

25

8

21

14x1.5

170

PHS 14 R/L

14x2.0

PHS 16 RF/LF

16

21

19.3

15

39

64

33

22

27

8

22

16x1.5

214

PHS 16 R/L

16x2.0

PHS 18 R/L

18

23

21.8

17

44

71

36

25

31

10

27

18x1.5

305

PHS 20 R/L

20

25

24.3

18

47

77

40

28

34

10

30

20x1.5

387

PHS 22 R/L

22

28

25.9

20

50

84

43

30

37

12

32

22x1.5

540

PHS 25 R/L

25

31

29.6

22

56

94

48

34

42

12

36

24x2.0

750

PHS 30 R/L

30

37

34.8

26

67

110

56

40

50

15

41

30x2.0

1,130
